3.7V 610mAh Explosion Proof Battery 200 Cycles High Capacity Lipo Battery

  • 1
  • 2

Brand Name : OiD

Model Number : OiD553735-600

Certification : Complies with GB 3836 series (China), IEC 60079 series (International), and ATEX Directive (EU).

Place of Origin : China

MOQ : 100pcs

Name : Explosion Proof Battery

Battery Type : 3.7V 820mAh Rechargeable

ODM : Free custom design for packs

Cathode : LiMn₂O₄ (LMO)

Cycle Life : 200+ cycles

Charging/ Discharging : 300mA/300mA

Operating Temperature : -10°C~45°C

Safety : Explosion Proof

Price : $0.5 ~ $100.0 / pcs

Delivery Time : 3 ~ 7 days for storage

Payment Terms : TT, L/C, Western Union

Contact Now

OiD553735-600 3.7V 610mAh 0.5C Discharge 200 Cycles Explosion Proof Lithium Battery

Product Name:

OiD553735-600 Explosion Proof Lithium Polymer Battery

Advantages:

  • High capacity and long cycle life
  • Explosion-proof design for enhanced safety
  • Reliable performance in various temperature conditions
  • RoHS compliant and environmentally friendly
  • Lightweight and compact design

Specifications:

Parameter

Value

Model

OiD553735-600

Nominal Voltage

3.7V

Minimum Capacity

600mAh (0.2C discharge)

Typical Capacity

610mAh (0.2C discharge)

Charging Cut-off Voltage

4.2V

Discharge Cut-off Voltage

3.0V

Max. Constant Charge Current

300mA (0.5C)

Max. Continuous Discharge Current

300mA (0.5C)

Weight

Approx. 16g

Storage Voltage

3.70-4.00V

Environmental Compliance

RoHS compliant

Cycle Life:

Condition

Cycle Life

Charge/Discharge Cycles

200 cycles at 0.5C charge/discharge at 23±2℃

Capacity Retention

≥70% after 200 cycles

Discharge Curve:

3.7V 610mAh Explosion Proof Battery 200 Cycles High Capacity Lipo Battery

Operating Temperature Range:

Condition

Temperature Range

Charging

5°C to 45°C (0.2C at 5-15°C, 0.5C at 15-45°C)

Discharging

-10°C to 45°C (0.2C at -10-15°C, 0.5C at 15-45°C)

Storage

-10°C to 45°C (1 month), -10°C to 35°C (6 months)

Certifications:

  • Complies with GB 3836 series (China), IEC 60079 series (International), and ATEX Directive (EU).

Key Features:

  • Explosion-proof design for enhanced safety
  • High discharge rate up to 0.5C
  • Built-in protection against overcharge, over-discharge, and short circuits
  • Low self-discharge rate
  • Lightweight and compact design

Applications:

  • Portable electronic devices
  • Medical devices
  • IoT devices
  • Wearable technology
  • Backup power systems

3.7V 610mAh Explosion Proof Battery 200 Cycles High Capacity Lipo Battery

Usage Warnings & Precautions:

  • Do not short-circuit the battery terminals.
  • Avoid exposing the battery to high temperatures or direct sunlight.
  • Use only the recommended charger for charging.
  • Do not disassemble or modify the battery.
  • In case of leakage, swelling, or overheating, stop using the battery immediately and dispose of it properly.

Storage Guidelines:

  • Store the battery at 20±5°C for optimal performance.
  • If storing for more than 3 months, charge the battery to 60% capacity every 3 months.
  • Avoid storing the battery in humid or high-temperature environments.

Warranty & Disclaimer:

  • 12-month warranty from the date of shipment.
  • The warranty does not cover damage caused by improper use, mishandling, or unauthorized modifications.
  • The manufacturer is not responsible for any accidents caused by failure to follow the specifications and precautions.
